Floorplanner Geometry Node

This geometry node asset allows you to turn a simple mesh outline of a floorplan into a quick 3d model of the walls floor and ceiling. With easy additions for door and wall cutouts.

Add the node to a mesh of edges that define the walls of a floorplan (use real scale for best results).

Use an edge attribute to define the outline of the floorplan and then add an optional floor and ceiling.

Add cutout objects to a collection and make that collection a "cutter" for the walls, floor or ceiling.
